Crydom 3G-OTH-38819 — Technical Specifications

Name: Crydom 3G-OTH-38819 CRYDOM Solid State Relay: Surface Mounted, 50 A Max Output Current, SCR, AC Output (MPN A53TP50D-10). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Saddle Clamp; Screw; Finger Safe: Yes; Input Current: 10 mA; Maximum Output Current without Heat Sink: Not Recommended; Mounting Style: Panel.
Brand: Crydom

The CRYDOM Solid State Relay: Surface Mounted (MPN A53TP50D-10) is a panel-mounted AC output relay with a Form A switch configuration. It features a saddle-clamp electrical connection, finger-safe design, and an input current of 10 mA. The output voltage range is 48 to 530V AC, and maximum output current without a heat sink is not recommended.

View Product & Quote

Technical Specifications

Parameter	Value
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	Yes
Current Type	AC
Input Current	10 mA
Mounting Style	Panel
Output Voltage	48 to 530V AC
Max Output Current	50 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Saddle Clamp
Manufacturer Part Number	A53TP50D-10
Maximum Output Current Without Heat Sink	Not Recommended
