Crydom 3G-OTH-38380 — Technical Specifications

Name: Crydom 3G-OTH-38380 CRYDOM Dual Solid State Relay: Surface Mounted, 25 A Max Output Current, SCR, AC Output (MPN CC4825W2U). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: Yes; Input Current: 10 mA; Maximum Output Current without Heat Sink: Not Recommended; Mounting Style: Panel; Output Voltage: 48 to 600V AC.
Brand: Crydom

The CRYDOM Dual Solid State Relay (MPN CC4825W2U) is a panel-mounted, AC-output relay with a Form A switch configuration and screw-clamp electrical connection. It features a 10 mA input current, an output voltage range of 48 to 600V AC, and is finger-safe. Maximum output current without a heat sink is not recommended.

View Product & Quote

Technical Specifications

Parameter	Value
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	Yes
Current Type	AC
Input Current	10 mA
Mounting Style	Panel
Output Voltage	48 to 600V AC
Max Output Current	25 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	CC4825W2U
Maximum Output Current Without Heat Sink	Not Recommended
