Crydom 3G-OTH-38442 — Technical Specifications

Name: Crydom 3G-OTH-38442 CRYDOM Dual Solid State Relay: Surface Mounted, 50 A Max Output Current, SCR, AC Output (MPN CC4850W3V). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: Yes; Input Current: 10 mA; Maximum Output Current without Heat Sink: Not Recommended; Mounting Style: Panel; Output Voltage: 48 to 600V AC.
Brand: Crydom

The CRYDOM Dual Solid State Relay (MPN CC4850W3V) is a panel-mounted, surface-mounted relay with a Form A switch configuration and AC output. It features a screw clamp electrical connection, is finger safe, and has an input current of 10 mA. The output voltage range is 48 to 600V AC, and operation without a heat sink is not recommended.

View Product & Quote

Technical Specifications

Parameter	Value
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	Yes
Current Type	AC
Input Current	10 mA
Mounting Style	Panel
Output Voltage	48 to 600V AC
Max Output Current	50 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	CC4850W3V
Maximum Output Current Without Heat Sink	Not Recommended
