Crydom 3G-OTH-40355 — Technical Specifications

Name: Crydom 3G-OTH-40355 CRYDOM Dual Solid State Relay: Surface Mounted, 25 A Max Output Current, SCR, AC Output (MPN CD2425W3V). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: No; Input Current: 10 mA; Maximum Output Current without Heat Sink: Not Recommended; Mounting Style: Panel; Output Voltage: 24 to 280V AC.
Brand: Crydom

The CRYDOM CD2425W3V is a panel-mounted, dual solid-state relay with a Form A switch configuration and AC output. It features a screw-clamp electrical connection, an input current of 10 mA, and an output voltage range of 24 to 280V AC. The maximum output current without a heat sink is not recommended.

View Product & Quote

Technical Specifications

Parameter	Value
Type	SCR, AC Output
Brand	CRYDOM
Finger Safe	No
Current Type	AC
Input Current	10 mA
Mounting Style	Panel
Output Voltage	24 to 280V AC
Max Output Current	25 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	CD2425W3V
Maximum Output Current Without Heat Sink	Not Recommended
