Crydom 3G-OTH-40342 — Technical Specifications

Name: Crydom 3G-OTH-40342 CRYDOM Solid State Relay: Surface Mounted, 5 A Max Output Current, Triac, AC Output (MPN CL240D05). Key specifications — Brand: CRYDOM; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: No; Maximum Output Current without Heat Sink: 2.9 A; Mounting Style: Panel; Output Voltage: 24 to 280V AC; Switch Configuration: Form A.
Brand: Crydom

The CRYDOM CL240D05 is a panel-mounted solid-state relay with a Form A (SPST-NO) switch configuration, providing AC output from 24 to 280V AC. It features a screw-clamp electrical connection and a maximum output current of 5 A, with a maximum output current without a heat sink of 2.9 A. This surface-mounted relay is designed for AC current applications and is not finger-safe.

View Product & Quote

Technical Specifications

Parameter	Value
Type	Triac, AC Output
Brand	CRYDOM
Finger Safe	No
Current Type	AC
Mounting Style	Panel
Output Voltage	24 to 280V AC
Max Output Current	5 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	CL240D05
Maximum Output Current Without Heat Sink	2.9 A
