Diode Led 3G-OTH-391158 — Technical Specifications

Name: Diode Led 3G-OTH-391158 DIODE LED Proximity Sensor Switch: LED, Passive Infrared (PIR), 12-24V DC, Vacancy, Hard Wired (MPN DI-SWTH-PRX). Key specifications — Communication Method: Hard Wired; Operating Voltage: 12-24V DC; Brand: DIODE LED; Load Rating @ 120V AC: 1CH x 5A, 1CH x 60W (12V), 1CH x 100W (24V); Sensor Brand: Diode LED.
Brand: Diode Led

The DIODE LED Proximity Sensor Switch is a wall-mount occupancy sensor from DIODE LED, operating on 12-24V DC with hard-wired communication. It features passive infrared (PIR) technology and vacancy mode, with a load rating of 1CH x 5A at 120V AC, 1CH x 60W (12V), and 1CH x 100W (24V).

View Product & Quote

Technical Specifications

Parameter	Value
DC	12-24V
Type	Passive Infrared (PIR), Vacancy, Hard Wired
Brand	DIODE LED
Sensor Brand	Diode LED
Operating Voltage	12-24V DC
Communication Method	Hard Wired
Load Rating @ 120V AC	1CH x 5A, 1CH x 60W (12V), 1CH x 100W (24V)
Manufacturer Part Number	DI-SWTH-PRX
