Dwyer 3G-OTH-91946 — Technical Specifications
The DWYER Window Sight Flow Indicator with Impeller: Rotor (MPN SFI-300SS-1/4) is a flow sight designed for non-corrosive fluids. It features a 316 stainless steel wetted material, a tempered glass sight, and a Buna-N seal, with a 1/4 in FNPT connection for vertical up flow direction.
Technical Specifications
| Parameter | Value |
|---|---|
| FNPT | 1/4 in |
| Type | FNPT |
| Brand | DWYER |
| Seal Material | Buna-N |
| Flow Direction | Vertical Up |
| For Media Type | Non-Corrosive Fluids |
| Sight Material | Tempered Glass |
| Connection Type | FNPT |
| Stainless Steel | 316 |
| Wetted Material | 316 Stainless Steel |
| Manufacturer Part Number | SFI-300SS-1/4 |
