Eaton 3G-OTH-35018 — Technical Specifications

Name: Eaton 3G-OTH-35018 EATON Selector Switch: 30 mm Panel Mounting Size, 3 Positions, Short Lever, 2NO, Metallic (MPN 10250ED1117-2KR). Key specifications — AC Contact Rating: 10 A @ 660 V; Action: Maintained/Maintained/Maintained; Cam: 3; DC Contact Rating: 5 A @ 250 V; Hazardous Location Specification: Not Rated; Operator Head Material: Polymer; Operator Head Type: Short-Handled Knob; Operator Illumination: Illuminated.
Brand: Eaton

The EATON 10250T Series Illuminated Selector Switch (SKU 39P811, MPN 10250ED1117-2KR) is a 30 mm panel-mounting illuminated selector switch with a polymer short-handled knob and metallic bezel. It features a maintained/maintained/maintained action across three positions (On-Off-On) with a 3-cam configuration. Electrical ratings are 10 A @ 660 V AC and 5 A @ 250 V DC. This switch is not rated for hazardous locations.

View Product & Quote

Technical Specifications

Parameter	Value
Cam	3
Type	Short Lever, 2NO, Metallic
Brand	EATON
Action	Maintained/Maintained/Maintained
Series	10250T
Positions	3
AC Contact Rating	10 A @ 660 V
DC Contact Rating	5 A @ 250 V
Operator Head Type	Short-Handled Knob
Operator Illumination	Illuminated
Operator Head Material	Polymer
Manufacturer Part Number	10250ED1117-2KR
Switch Bezel Material Type	Metallic
Switch Function @ 1st Position	On
Switch Function @ 2nd Position	Off
Switch Function @ 3rd Position	On
Switch Function @ 4th Position	No Fourth Position
Hazardous Location Specification	Not Rated
