Gmn 3G-OTH-101683 — Technical Specifications
The GMN Super Precision Angular Contact Bearing S 619/8 is a single, metric bearing with an ABEC P4 rating. It features a 15° contact angle, an open design, and a phenolic cage, with an 8 mm bore. This bearing is supplied as a single, unmatched unit under manufacturer part number S619/8 CTA P4+ UL.
Technical Specifications
| Parameter | Value |
|---|---|
| Bore | 8 mm |
| Type | 15°, Open, ABEC P4, Phenolic Cage |
| Brand | GMN |
| ABEC Rating | P4 |
| Bearing Type | Single Bearing |
| Contact Bearing Type | Angular Contact |
| Matched Bearing Type | Not Matched/Single Bearing |
| System Of Measurement | Metric |
| Bearing Industry Number | S 619/8 |
| Manufacturer Part Number | S619/8 CTA P4+ UL |
