Harris 3G-OTH-359361 — Technical Specifications
The HARRIS Gas Regulator: Single Stage is a fuel gas regulator with a CGA 300 inlet and a 9/16"-18 M LH outlet. It features a fiber reinforced neoprene diaphragm and is designed for acetylene service, with a 15 psig outlet pressure rating (MPN 25-15C-300).
Technical Specifications
| Parameter | Value |
|---|---|
| Type | CGA 300 Inlet, 15 psig, Acetylene |
| Brand | HARRIS |
| LH Outlet | 9/16"-18 M |
| Inlet Connection | CGA 300 |
| Outlet Connection | 9/16"-18 M LH |
| Diaphragm Material | Fiber Reinforced Neoprene |
| Manufacturer Part Number | 25-15C-300 |
