Heli-coil 3G-OTH-527871 — Technical Specifications
The HELI-COIL Thread Repair Kit (MPN 5402-6) is a tanged tang style insert and tool kit for repairing 3/8"-24 fine threads in metal. It includes 18-8 stainless steel helical inserts with a free-running, plain finish and a right-hand thread direction. The kit comes with an STI tap sized 3/8"-24, making it a complete solution for restoring damaged inch-system threads.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Free-Running, Stainless Steel |
| Brand | HELI-COIL |
| Finish Type | Plain |
| Thread Size | 3/8"-24 |
| Thread Type | Fine |
| STI Tap Size | 3/8"-24 |
| Thread Direction | Right Hand |
| Compatible Material | Metal |
| Material Grade/Class | 18-8 |
| Insert Types Included | Helical Inserts |
| System Of Measurement | Inch |
| Manufacturer Part Number | 5402-6 |
