Iptci Bearings 3G-OTH-103996 — Technical Specifications
The IPTCI BEARINGS Insert Bearing CL206-18 is a general purpose spherical insert bearing with a ball bearing insert type. It features a 1 1/8 inch bore, 62 mm outer diameter, and 0.708 inch outer ring width, with double sealed closure for protection. This inch-system bearing is identified by industry number CL206-18.
Technical Specifications
| Parameter | Value |
|---|---|
| OD | 62 mm |
| Bore | 1 1/8 in |
| Type | Spherical |
| Brand | IPTCI BEARINGS |
| Closure | Double Sealed |
| Outer Ring Wd | 0.708 in |
| Bearing Insert Type | Ball |
| System Of Measurement | Inch |
| Bearing Industry Number | CL206-18 |
| Manufacturer Part Number | CL206-18 |
