Johnson Controls 3G-OTH-68474 — Technical Specifications
The JOHNSON CONTROLS HE-69S30NP-0 is a duct-mounted temperature and humidity sensor with a plastic housing and no display. It provides a 0 to 10V DC humidity output, with a relative humidity range of 20 to 80% and accuracy of ±3% of full scale, and temperature accuracy of ±1.00°F. The unit connects via screw terminals and is compatible with building automation systems, including a certificate of calibration conformance.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | -40°F to 212°F, Plastic, Single Measurement, Plastic |
| Brand | JOHNSON CONTROLS |
| Display | No Display |
| Housing | Plastic |
| Includes | Test and Calibration Equipment Certificate of Calibration Conformance |
| Product Type | Duct Temperature and Humidity Sensor |
| Humidity Output | 0 to 10V DC |
| Mounting Location | Duct Mount |
| Temperature Accuracy | ±1.00°F |
| Relative Humidity Range | 20 to 80% |
| Manufacturer Part Number | HE-69S30NP-0 |
| Electrical Connection Type | Screw Terminals |
| Relative Humidity Accuracy | ±3% of Full Scale |
| For Use With Building Automation Systems | Building Automation System Compatible |
