Johnson Controls 3G-OTH-67040 — Technical Specifications

Name: Johnson Controls 3G-OTH-67040 Actuator: Dampers/VAV Boxes/Zone Valves, Floating Point, Non-Spring Return, 35 in-lb, 24V AC (MPN M9104-AGA-2S). Key specifications — Manufacturer Part Number: M9104-AGA-2S; Shaft Rotation: CW/CCW; Stroke Degree: 93°; Plenum Rating: Plenum Rated; Input Voltage: 24V AC; Brand: JOHNSON CONTROLS; For Use With Building Automation Systems: Building Automation System Compatible; Electrical Connection Type: Hardwired.
Brand: Johnson Controls

The JOHNSON CONTROLS M9104-AGA-2S is a non-fail-safe actuator for dampers, VAV boxes, and zone valves, operating on 24V AC with a 93° stroke and CW/CCW shaft rotation. This plenum-rated, hardwired unit is building automation system compatible and features a floating point, non-spring return design with 35 in-lb torque.

View Product & Quote

Technical Specifications

Parameter	Value
AC	24V
Type	Floating Point, Non-Spring Return, 35 in-lb
Brand	JOHNSON CONTROLS
Input Voltage	24V AC
Plenum Rating	Plenum Rated
Stroke Degree	93°
Shaft Rotation	CW/CCW
Manufacturer Part Number	M9104-AGA-2S
Auxiliary Switch Included	No
Electrical Connection Type	Hardwired
For Use With Building Automation Systems	Building Automation System Compatible
