Johnson Controls 3G-OTH-67281 — Technical Specifications
The JOHNSON CONTROLS M9203-GGB-2Z is a proportional, spring-return fail-safe damper actuator with a 95° stroke and CW/CCW shaft rotation. It operates on 24V AC with a 1.9W power rating and provides a 0 to 10V DC output signal. This plenum-rated, hardwired actuator includes an auxiliary switch and is compatible with building automation systems.
Technical Specifications
| Parameter | Value |
|---|---|
| AC | 24V |
| Type | Proportional, Spring Return, 27 in-lb, Hardwired Plenum Rated Cables |
| Brand | JOHNSON CONTROLS |
| Power Rating | 1.9W |
| Input Voltage | 24V AC |
| Output Signal | 0 to 10V DC |
| Plenum Rating | Plenum Rated |
| Stroke Degree | 95° |
| Shaft Rotation | CW/CCW |
| Manufacturer Part Number | M9203-GGB-2Z |
| Auxiliary Switch Included | Yes |
| Electrical Connection Type | Hardwired |
| For Use With Building Automation Systems | Building Automation System Compatible |
