Johnson Controls 3G-OTH-68085 — Technical Specifications
The JOHNSON CONTROLS M9208-BAA-3 is a fail-safe spring-return damper actuator with a 90° stroke and CW/CCW shaft rotation. It operates on 120V AC input voltage, features a self-centering clamping shaft, and is hardwired for electrical connection. This NEMA 2 / IP54 rated actuator is building automation system compatible and delivers 70 in-lb of torque.
Technical Specifications
| Parameter | Value |
|---|---|
| AC | 120V |
| Type | On/Off, Spring Return, 70 in-lb, Hardwired, NEMA 2 / IP54 |
| Brand | JOHNSON CONTROLS |
| Shaft Type | Self-Centering Clamping |
| Input Voltage | 120V AC |
| Stroke Degree | 90° |
| Shaft Rotation | CW/CCW |
| Manufacturer Part Number | M9208-BAA-3 |
| Auxiliary Switch Included | No |
| Electrical Connection Type | Hardwired |
| For Use With Building Automation Systems | Building Automation System Compatible |
