Johnson Controls 3G-OTH-68078 — Technical Specifications
The JOHNSON CONTROLS M9208-BDC-3 is a fail-safe spring return damper actuator with a 90° stroke and CW/CCW shaft rotation. It operates on 230V AC with hardwired electrical connection and includes an auxiliary switch. The self-centering clamping shaft is designed for use with building automation systems.
Technical Specifications
| Parameter | Value |
|---|---|
| AC | 230V |
| Type | On/Off, Spring Return, 70 in-lb, Hardwired, NEMA 2 / IP54 |
| Brand | JOHNSON CONTROLS |
| Shaft Type | Self-Centering Clamping |
| Input Voltage | 230V AC |
| Stroke Degree | 90° |
| Shaft Rotation | CW/CCW |
| Manufacturer Part Number | M9208-BDC-3 |
| Auxiliary Switch Included | Yes |
| Electrical Connection Type | Hardwired |
| For Use With Building Automation Systems | Building Automation System Compatible |
