Mcdonnell & Miller 3G-OTH-93930 — Technical Specifications
The MCDONNELL & MILLER FS7-4W is a paddle-type insertion-style flow switch for liquids, designed for pipe sizes from 1-1/4 in to 16 in. It features a brass body with a 1-1/4 in NPT connection and an SPDT switch rated at 7.4 A @ 120V (Full Load). This switch carries a hazardous location rating of Class I, Div 1 and 2, Group C, D.
Technical Specifications
| Parameter | Value |
|---|---|
| NPT | 1 1/4 in |
| Type | 1 1/4 in/16 in For Pipe Size, Brass, NPT, SPDT |
| Brand | MCDONNELL & MILLER |
| For Pipe Size | 1-1/4 in |
| Contact Rating (AC) | 7.4 A @ 120V (Full Load) |
| Manufacturer Part Number | FS7-4W |
| Hazardous Location Rating | Class I, Div 1 and 2, Group C, D |
