Metz Connect 3G-OTH-52914 — Technical Specifications

Name: Metz Connect 3G-OTH-52914 Sensor Cable: M12 Male Straight X Free End, 5 Pins, Black, PUR, 5 m Cable Lg, 4 A Max Current (A) (MPN 142MDA20050). Key specifications — Cable Jacket Color: Black; End 1 Gender: Male; End 1 Mounting Orientation: Straight; End 2 Connection Type: Free End; IP Rating: IPX7; Brand: METZ CONNECT; Wire Size: 22 AWG/42 AWG; Cable Jacket Material: PUR.
Brand: Metz Connect

The METZ CONNECT Sensor Cable is a single-ended cordset with a PUR jacket for twisting applications. This M12 male straight connector features a free-end termination, 5 pins, a 5 m cable length, and a 4 A max current rating. It is rated IPX7 and uses 22 AWG/42 AWG wire with a black PUR jacket.

View Product & Quote

Technical Specifications

Parameter	Value
Pins	5
Type	Black, PUR
Brand	METZ CONNECT
Cable Lg	5 m
IP Rating	IPX7
Wire Size	22 AWG/42 AWG
End 1 Gender	Male
Max Current (A)	4 A
Cable Jacket Color	Black
Cable Jacket Material	PUR
End 1 Connection Type	M12
End 2 Connection Type	Free End
Manufacturer Part Number	142MDA20050
End 1 Mounting Orientation	Straight
