Nicholson 3G-OTH-69912 — Technical Specifications
The NICHOLSON FTN-C4E9A is a cast iron C-pattern float and thermostatic steam trap from the FTN series. It features a 1 in FNPT connection, a maximum capacity of 1,450 lb/hr, a maximum pressure of 75 psi, and a maximum temperature of 450°F. Designed for horizontal installation, this steam trap is constructed with a cast iron float.
Technical Specifications
| Parameter | Value |
|---|---|
| FNPT | 1 in |
| Max. | 75 psi |
| Type | 1,450 lb/hr, C Pattern |
| Brand | NICHOLSON |
| Float Material | Cast Iron |
| Manufacturer Series | FTN |
| Installation Orientation | Horizontal |
| Manufacturer Part Number | FTN-C4E9A |
