Ntn 3G-OTH-107654 — Technical Specifications
The NTN SUCFB207 is a food-grade flange-mount ball bearing with a 35 mm cylindrical bore, stainless steel construction, and set screw locking. It features FDA/USDA-H1 solid grease lubrication and M10 mounting bolts, with dimensions of 90 mm length and 44.4 mm width. This metric 3-bolt flange bearing does not include a bearing cap.
Technical Specifications
| Parameter | Value |
|---|---|
| Lg | 90 mm |
| Wd | 44.4 mm |
| Bore | 35 mm |
| Type | SS, Set Screws |
| Brand | NTN |
| Bore Type | Cylindrical |
| Lubricant Material | FDA/USDA-H1 Solid Grease |
| Mounting Bolt Size | M10 |
| Included Bearing Cap | None |
| System Of Measurement | Metric |
| Manufacturer Part Number | SUCFB207 |
