Omron 3G-OTH-40284 — Technical Specifications

Name: Omron 3G-OTH-40284 OMRON Solid State Relay: Surface Mounted, 10 A Max Output Current, Photocoupler, AC Output (MPN G3NA-610B-DC5-24). Key specifications — Brand: OMRON; Current Type: DC; Electrical Connection: Screw Clamp; Finger Safe: Yes; Input Current: 0.6 to 15 A; Maximum Output Current without Heat Sink: 4 A; Mounting Style: Surface; Output Voltage: 400 to 600V AC.
Brand: Omron

The OMRON Solid State Relay: Surface Mounted (SKU 1YDL5, MPN G3NA-610B-DC5-24) is a surface-mounted relay with a DC input current range of 0.6 to 15 A and an AC output voltage of 400 to 600V AC. It features a Form A switch configuration, a screw clamp electrical connection, and is finger safe. The maximum output current without a heat sink is 4 A.

View Product & Quote

Technical Specifications

Parameter	Value
Type	Photocoupler, AC Output
Brand	OMRON
Finger Safe	Yes
Current Type	DC
Input Current	0.6 to 15 A
Mounting Style	Surface
Output Voltage	400 to 600V AC
Max Output Current	10 A
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	G3NA-610B-DC5-24
Maximum Output Current Without Heat Sink	4 A
