Protec 3G-OTH-23060 — Technical Specifications

Name: Protec 3G-OTH-23060 PROTEC Surge Protection: Single Phase, 120V AC, 1 Poles, 2 Wires, L-G/L-N, 700V (L-G)/700V (L-N) (MPN ASISP150-1P). Key specifications — Voltage: 120V AC; Number of Wires: 2 Wires; Modes of Protection: L-G; Max. Continuing Operating Voltage: 150 V AC (L-G); 150 V AC (L-N); Voltage Protection Rating: 700V (L-N); Short Circuit Current Rating: 200 kA; Mounting Style: DIN-Rail.
Brand: Protec

The PROTEC Surge Protection: Single Phase (SKU 808CH1) is a DIN Rail internal-mount SPD from the OEM brand PROTEC. It is rated for 120V AC with a 200 kA short circuit current rating, a 700V (L-N) voltage protection rating, and a max. continuing operating voltage of 150 V AC (L-G). This 2-wire, L-G mode device is designed for single-phase applications.

View Product & Quote

Technical Specifications

Parameter	Value
AC	120V
Type	L-G/L-N, 700V (L-G)/700V (L-N)
Brand	PROTEC
Poles	1
Wires	2
Voltage	120V AC
Mounting Style	DIN-Rail
Number Of Wires	2 Wires
Modes Of Protection	L-G
Manufacturer Part Number	ASISP150-1P
Voltage Protection Rating	700V (L-N)
Short Circuit Current Rating	200 kA
Max. Continuing Operating Voltage	150 V AC (L-G)
