Ranco 3G-OTH-68624 — Technical Specifications
The RANCO RHS-665565 is a single-pressure high-limit pressure switch with an SPST contact form, rated for 36V DC. It features an Open on Fall switch action with a pressure set point range of 0 psi to 735 psi and a pressure differential of 100 psi, and is configured for auto reset.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | Auto Reset, 0 psi to 735 psi, 100 psi, Open on Fall, SPST |
| Brand | RANCO |
| Contact Form | SPST |
| Rated Voltage | 36V DC |
| Switch Action | Open on Fall |
| Pressure Set Point | 0 psi to 735 psi |
| Pressure Differential | 100 psi |
| Manufacturer Part Number | RHS-665565 |
