Solahd 3G-OTH-22636 — Technical Specifications

Name: Solahd 3G-OTH-22636 SOLAHD Surge Protection Device: Single Phase, 120V AC, 1 Poles, 2 + Ground Wires, L-G/L-N/N-G, 5kAIC (MPN STFE05010N). Key specifications — Voltage: 120V AC; Number of Wires: 2 Wires + Ground; Modes of Protection: L-G; Max. Continuing Operating Voltage: 150 V AC; Voltage Protection Rating: 400V (L-N); Short Circuit Current Rating: 5kAIC; Filtering: Yes; Enclosure Material: Metal.
Brand: Solahd

The SOLAHD Surge Protection Device is a single-phase, DIN Rail internal-mount SPD with a metal enclosure. It operates at 120V AC with a maximum continuous operating voltage of 150V AC, providing L-G mode protection and a voltage protection rating of 400V (L-N). The unit features filtering, supports 2 wires plus ground, and has a short circuit current rating of 5kAIC.

View Product & Quote

Technical Specifications

Parameter	Value
AC	120V
Type	2 + Ground Wires, L-G/L-N/N-G, 5kAIC
Brand	SOLAHD
Poles	1
Voltage	120V AC
Filtering	Yes
Mounting Style	DIN-Rail
Number Of Wires	2 Wires + Ground
Enclosure Material	Metal
Modes Of Protection	L-G
Manufacturer Part Number	STFE05010N
Voltage Protection Rating	400V (L-N)
Short Circuit Current Rating	5kAIC
Max. Continuing Operating Voltage	150 V AC
