Square D 3G-OTH-40921 — Technical Specifications
The SQUARE D Magnetic Motor Starter is a non-reversing starter with thermal overloads, designed for three-phase applications. This NEMA Size 1 unit features a 220/240V AC coil, 27 A rating, and 2 poles, with screw clamp terminals. It requires one melting alloy thermal unit (not included) and includes no auxiliary contacts, operator controls, or pilot light.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | NEMA Size 1, 27 A |
| Brand | SQUARE D |
| Phase | Three |
| Poles | 2 |
| AC Coil | 240V |
| Operator | None |
| Coil Voltage | 220/240V AC |
| Operator Controls | None |
| Includes Pilot Light | No |
| Thermal Units Required | 1 Melting Alloy Unit (Not Included) |
| Manufacturer Part Number | 8536SCO2V03 |
| Terminal Connection Type | Screw Clamp Terminals |
| Auxiliary Contacts Included | No Auxiliary Contacts Included |
