Square D 3G-OTH-42508 — Technical Specifications
The SQUARE D NEMA Magnetic Motor Starter is a reversing starter with electronic overloads, designed for three-phase applications. This NEMA Size 3 unit features a 90 A rating and a 120V AC coil, with screw clamp terminals for secure wiring. It includes no operator, pilot light, or auxiliary contacts, and thermal units are not required due to the electronic overloads.
Technical Specifications
| Parameter | Value |
|---|---|
| Type | NEMA Size 3, 90 A |
| Brand | SQUARE D |
| Phase | Three |
| Poles | 3 |
| AC Coil | 120V |
| Operator | None |
| Coil Voltage | 120V AC |
| Operator Controls | None |
| Includes Pilot Light | No |
| Thermal Units Required | None (Not Applicable to Electronic Overloads) |
| Manufacturer Part Number | 8736SEO2V02H30S |
| Terminal Connection Type | Screw Clamp Terminals |
| Auxiliary Contacts Included | No Auxiliary Contacts Included |
