APPROVED VENDOR Helical Insert: Tanged Tang Style, Free-Running, 5/8"-18 Thread Size, Plain - Free-Running Tanged Helical Inserts
APPROVED VENDORFree-Running Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Free-Running, 5/8"-18 Thread Size, Plain

The APPROVED VENDOR Helical Insert is a free-running, tanged tang style insert in a 5-pack, featuring a 5/8"-18 thread size with fine, right-hand threads. Made from 18-8 stainless steel, it offers a tensile strength…

SKU 3G-OTH-598960

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Free-Running, 5/8"-18 Thread Size, Plain
Category
Free-Running Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3534-5/8X1.5D
Type
Free-Running, Plain, 5 PK
Thread Size
5/8"-18
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Helical Insert is a free-running, tanged tang style insert in a 5-pack, featuring a 5/8"-18 thread size with fine, right-hand threads. Made from 18-8 stainless steel, it offers a tensile strength of 200,000 psi and is designed for plain, inch-series applications.

Frequently Asked Questions

What is an APPROVED VENDOR helical insert used for?

This free-running tanged tang helical insert repairs or reinforces tapped threads in metal assemblies. It is commonly used in industrial machinery, automotive, and aerospace applications where a strong, wear-resistant 5/8"-18 thread is needed. The 18-8 stainless steel construction provides corrosion resistance and a tensile strength of 200,000 psi.

What are the specifications of the APPROVED VENDOR 3534-5/8X1.5D helical insert?

The insert has a 5/8"-18 thread size with fine, right-hand threads. It is free-running, plain finish, and made from 18-8 stainless steel. Tensile strength is 200,000 psi. The pack contains 5 pieces. It is designed for inch-series applications and is manufactured by APPROVED VENDOR.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us to order the 5/8"-18 free-running tanged tang insert (MPN 3534-5/8X1.5D) for your application.

How to install a tanged tang helical insert?

Drill out the damaged thread to the specified tap drill size, then tap the hole with the correct STI tap. Using a tang break-off tool, insert the helical insert until it is slightly below the surface. After installation, break off the tang with a punch. Always follow the manufacturer's instructions for torque and depth.
