ARROW Door Lockset: Classroom Lever Locksets, Chrome, ADA Compliant
The ARROW Door Lockset is a Classroom Lever Lockset (MPN BM17 XL 26D) with a Satin Chromium-Plated Brass finish, ADA compliant and featuring an interchangeable core. It is a curved-lip style, non-ligature-resistant…
SKU 3G-OTH-508699
Need installation or engineering help?
Ask a question
Product Description
The ARROW Door Lockset is a Classroom Lever Lockset (MPN BM17 XL 26D) with a Satin Chromium-Plated Brass finish, ADA compliant and featuring an interchangeable core. It is a curved-lip style, non-ligature-resistant, with ANSI function code F05 and no visual indicator.
Frequently Asked Questions
What is the ARROW BM17 XL 26D classroom lever lockset used for?
The ARROW BM17 XL 26D is a classroom lever lockset designed for educational facilities. Its ANSI F05 function allows key-locking from outside while inside egress is always free, meeting school security and life-safety requirements. The satin chromium-plated brass finish resists wear in high-traffic corridors.
What are the specifications of the ARROW BM17 XL 26D lockset?
The ARROW BM17 XL 26D is a classroom lever lockset with a satin chromium-plated brass finish. It is ADA compliant, features a curved lip, and uses an interchangeable core. The ANSI function code is F05. It is not ligature-resistant and has no visual indicator message.
Where to buy the ARROW BM17 XL 26D lockset worldwide?
3G Electric supplies the ARROW BM17 XL 26D classroom lever lockset to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for a quote and lead time on this ARROW model.
How to install an ARROW classroom lever lockset?
Installation of the ARROW BM17 XL 26D follows standard cylindrical lockset procedures: prepare the door for a 2-1/8" bore and 1-1/2" latch edge, mount the chassis, attach the curved-lip strike, and set the interchangeable core. Always verify ADA lever height and torque specifications per local codes.
