ARROW Door Lockset: Classroom Lever Locksets, Chrome, ADA Compliant
ARROWClassroom Lever Locksets

ARROW Door Lockset: Classroom Lever Locksets, Chrome, ADA Compliant

The ARROW Door Lockset is a Classroom Lever Lockset (ANSI F84) with a satin chromium-plated zinc finish, ADA compliant and featuring an interchangeable core. Supplied with an RL Rose style and no visual indicator…

SKU 3G-OTH-508820

Brand
ARROW
Item
Door Lockset: Classroom Lever Locksets, Chrome, ADA Compliant
Category
Classroom Lever Locksets
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ARROW
Manufacturer Part Number
RL17SR 26D
Type
Chrome, ADA Compliant, Interchangeable Core
Finish
Satin Chromium-Plated : Zinc
ADA Compliant
Yes
Lockset Style
RL Rose
Ligature Resistance
Not Ligature-Resistant
Visual Indicator Message
No Message
Lockset Function ANSI Code
F84
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ARROW Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ARROW Door Lockset is a Classroom Lever Lockset (ANSI F84) with a satin chromium-plated zinc finish, ADA compliant and featuring an interchangeable core. Supplied with an RL Rose style and no visual indicator message, this lockset is not ligature-resistant.

Frequently Asked Questions

What is the ARROW RL17SR 26D door lockset used for?

The ARROW RL17SR 26D is a classroom lever lockset (ANSI F84) designed for educational and commercial facilities. It provides secure passage control with an interchangeable core for quick rekeying, and its ADA-compliant lever meets accessibility requirements.

What are the specifications of the ARROW RL17SR 26D lockset?

This ARROW lockset has a satin chromium-plated zinc finish, ANSI F84 classroom function, RL Rose style, and is ADA compliant. It features an interchangeable core, no visual indicator, and is not ligature-resistant. The manufacturer part number is RL17SR 26D.

Where to buy the ARROW RL17SR 26D lockset worldwide?

3G Electric supplies the ARROW RL17SR 26D classroom lever lockset to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this item.

How to install the ARROW RL17SR 26D classroom lockset?

Installation follows standard cylindrical lockset procedures: prepare the door with correct backset and bore, mount the chassis, attach the lever and rose, and install the interchangeable core per ARROW instructions. Always verify handing and ADA lever orientation before final tightening.
