ASHCROFT Pressure Transmitter: -15 psi to 15 psi, 4 to 20mA DC, Hirschmann Form A DIN 43650-A - Intrinsically Safe with DIN 43650 Form A Connector
ASHCROFTIntrinsically Safe with DIN 43650 Form A Connector

ASHCROFT Pressure Transmitter: -15 psi to 15 psi, 4 to 20mA DC, Hirschmann Form A DIN 43650-A

The ASHCROFT A4 Series pressure transmitter (SKU 5DDF3) is an intrinsically safe-rated compound transmitter with a -15 psi to 15 psi range and 4 to 20mA DC output. It features a stainless steel housing, IP65/NEMA 4X…

SKU 3G-OTH-176585

Brand
ASHCROFT
Item
Pressure Transmitter: -15 psi to 15 psi, 4 to 20mA DC, Hirschmann Form A DIN 43650-A
Category
Intrinsically Safe with DIN 43650 Form A Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
A4SBM0242D015#&VAC
Series
A4
Type
Hirschmann® Form A DIN 43650-A, IP65 /4X
DC
4 to 20mA
Output
4 to 20mA DC
Accuracy
±0.50% of Full Scale
IP Rating
IP65
NEMA Rating
4X
Overpressure
1.5x Range
Product Type
Intrinsically Safe-Rated Transmitter
Safety Rating
Class II, Div 1 and 2, Group F, G
Burst Pressure
2x Range
Pressure Range
-15 psi to 15 psi
Housing Material
Stainless Steel
Intrinsically Safe
Intrinsically Safe
Electrical Connection
Hirschmann® Form A DIN 43650-A
Pressure Type Measured
Compound
Process Connection Type
NPT
NIST Traceable Certificate
NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT A4 Series pressure transmitter (SKU 5DDF3) is an intrinsically safe-rated compound transmitter with a -15 psi to 15 psi range and 4 to 20mA DC output. It features a stainless steel housing, IP65/NEMA 4X rating, Hirschmann® Form A DIN 43650-A electrical connection, and NPT process connection. Accuracy is ±0.50% of full scale, with overpressure of 1.5x range and burst pressure of 2x range. A NIST-traceable calibration certificate is included.

Frequently Asked Questions

What is the ASHCROFT A4 pressure transmitter used for?

The ASHCROFT A4 series pressure transmitter is used for compound pressure measurement in hazardous industrial environments. It is intrinsically safe rated for Class II, Div 1 and 2, Group F, G, making it suitable for applications in chemical processing, oil and gas, and power generation where safety is critical.

What are the specifications of the ASHCROFT A4 pressure transmitter?

The ASHCROFT A4 transmitter (MPN A4SBM0242D015#&VAC) has a pressure range of -15 psi to 15 psi with 4 to 20mA DC output. It features a stainless steel housing, IP65/NEMA 4X rating, Hirschmann® Form A DIN 43650-A connection, and NPT process connection. Accuracy is ±0.50% of full scale, with overpressure of 1.5x range and burst pressure of 2x range.

Where to buy the ASHCROFT A4 pressure transmitter worldwide?

3G Electric supplies the ASHCROFT A4 pressure transmitter worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time. We source and deliver this intrinsically safe transmitter to customers in any country.

How to install the ASHCROFT A4 pressure transmitter?

Install the ASHCROFT A4 transmitter by connecting the NPT process connection to the system using appropriate sealant. Wire the 4 to 20mA DC output to the Hirschmann® Form A DIN 43650-A connector per the wiring diagram. Ensure the housing is properly grounded and the IP65/NEMA 4X seal is maintained. Follow standard hazardous area installation practices for intrinsically safe equipment.
