ASHCROFT Pressure Transmitter: -15 psi to 15 psi, 4 to 20mA DC, Hirschmann Form A DIN 43650-A - Intrinsically Safe with DIN 43650 Form A Connector
ASHCROFTIntrinsically Safe with DIN 43650 Form A Connector

ASHCROFT Pressure Transmitter: -15 psi to 15 psi, 4 to 20mA DC, Hirschmann Form A DIN 43650-A

The ASHCROFT A4 Series Pressure Transmitter is an intrinsically safe-rated transmitter with a compound pressure range of -15 psi to 15 psi. It features a 4 to 20mA DC output, ±0.50% of Full Scale accuracy, and a…

SKU 3G-OTH-176547

Brand
ASHCROFT
Item
Pressure Transmitter: -15 psi to 15 psi, 4 to 20mA DC, Hirschmann Form A DIN 43650-A
Category
Intrinsically Safe with DIN 43650 Form A Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
A4SBF0242D015#&VAC
Series
A4
Type
Hirschmann® Form A DIN 43650-A, IP65 /4X
DC
4 to 20mA
Output
4 to 20mA DC
Accuracy
±0.50% of Full Scale
IP Rating
IP65
NEMA Rating
4X
Overpressure
1.5x Range
Product Type
Intrinsically Safe-Rated Transmitter
Safety Rating
Class II, Div 1 and 2, Group F, G
Burst Pressure
2x Range
Pressure Range
-15 psi to 15 psi
Housing Material
Stainless Steel
Intrinsically Safe
Intrinsically Safe
Electrical Connection
Hirschmann® Form A DIN 43650-A
Pressure Type Measured
Compound
Process Connection Type
NPT
NIST Traceable Certificate
NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT A4 Series Pressure Transmitter is an intrinsically safe-rated transmitter with a compound pressure range of -15 psi to 15 psi. It features a 4 to 20mA DC output, ±0.50% of Full Scale accuracy, and a stainless steel housing with IP65 and NEMA 4X ratings. The unit includes a Hirschmann® Form A DIN 43650-A electrical connection and an NPT process connection, with a NIST-Traceable Calibration Certificate included.

Frequently Asked Questions

What is the ASHCROFT A4 pressure transmitter used for?

The ASHCROFT A4 Series Pressure Transmitter is used for precise compound pressure measurement from -15 psi to 15 psi in hazardous industrial environments. Its intrinsically safe rating (Class II, Div 1 and 2, Group F, G) and IP65/NEMA 4X stainless steel housing make it suitable for oil and gas, chemical processing, and wastewater applications where safety and durability are critical.

What are the specifications of the ASHCROFT A4 pressure transmitter?

The ASHCROFT A4 transmitter has a compound pressure range of -15 psi to 15 psi, 4 to 20mA DC output, ±0.50% of Full Scale accuracy, and a Hirschmann® Form A DIN 43650-A electrical connection. It features an NPT process connection, stainless steel housing, IP65/NEMA 4X ratings, and includes a NIST-Traceable Calibration Certificate.

Where to buy the ASHCROFT A4 pressure transmitter worldwide?

3G Electric supplies the ASHCROFT A4 Series Pressure Transmitter worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time on this intrinsically safe transmitter with DIN 43650 Form A connector.

How to select the right ASHCROFT pressure transmitter for hazardous areas?

To select the right ASHCROFT pressure transmitter, verify the hazardous area classification (e.g., Class II, Div 1, Group F) and confirm the transmitter's intrinsically safe rating matches. Check the pressure range, output signal (4 to 20mA DC), process connection (NPT), and environmental protection (IP65/NEMA 4X). 3G Electric can help interpret your application requirements.
