ASHCROFT Pressure Transmitter: 0 psi to 60 psi, 4 to 20mA DC
The ASHCROFT G2 Series Pressure Transmitter with 4-Pin Mini-DIN Connector (SKU 5DEJ1) measures 0 psi to 60 psi with a 4 to 20mA DC output and ±0.5% accuracy. It features an IP67 and NEMA 4X rated nylon housing…
SKU 3G-OTH-176263
Need installation or engineering help?
Ask a question
Product Description
The ASHCROFT G2 Series Pressure Transmitter with 4-Pin Mini-DIN Connector (SKU 5DEJ1) measures 0 psi to 60 psi with a 4 to 20mA DC output and ±0.5% accuracy. It features an IP67 and NEMA 4X rated nylon housing, overpressure of 2x range, and burst pressure of 10x range. The SAE male process connection and 4-Pin Mini-DIN Hirschmann G Series connector enable straightforward integration. No NIST-traceable calibration certificate is included.
Frequently Asked Questions
What is the ASHCROFT G2 pressure transmitter used for?
The ASHCROFT G2 pressure transmitter measures 0 psi to 60 psi with a 4 to 20mA DC output. It is used in industrial applications requiring accurate pressure monitoring, such as hydraulic systems, pumps, and process control, where its IP67 and NEMA 4X rated nylon housing provides protection in wet or corrosive environments.
What are the specifications of the ASHCROFT G2 pressure transmitter?
The ASHCROFT G2 pressure transmitter (MPN G17MEK42M160#) has a range of 0 psi to 60 psi, accuracy ±0.5%, output 4 to 20mA DC, overpressure 2x range, burst pressure 10x range, IP67 and NEMA 4X rating, nylon housing, SAE male process connection, and a 4-Pin Mini-DIN Hirschmann G Series connector. No NIST-traceable calibration certificate is included.
Where to buy the ASHCROFT G2 pressure transmitter worldwide?
3G Electric supplies the ASHCROFT G2 pressure transmitter worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time. We source and deliver this transmitter to support your operations anywhere in the world.
How to install the ASHCROFT G2 pressure transmitter?
Install the ASHCROFT G2 pressure transmitter by connecting the SAE male process port to a compatible female port using appropriate sealing. Wire the 4-Pin Mini-DIN Hirschmann G Series connector per the pinout for 4 to 20mA DC loop power. Ensure the housing is not overtightened and the IP67 seal is intact. Follow standard industrial wiring practices.
Used in
Common applications for ASHCROFTASHCROFT Products
3G Electric supplies ASHCROFT pressure transmitters with 4-pin mini-din connector. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
