ASHCROFT Pressure Transmitter: 0 psi to 100 psi, 4 to 20mA DC - Pressure Transmitters with 4-Pin Mini-DIN Connector
ASHCROFTPressure Transmitters with 4-Pin Mini-DIN Connector

ASHCROFT Pressure Transmitter: 0 psi to 100 psi, 4 to 20mA DC

The ASHCROFT G2 Pressure Transmitter (0 psi to 100 psi) is a pressure transmitter with a 4-Pin Mini-DIN connector, offering a 4 to 20mA DC output. It features ±0.5% accuracy, an IP67 and NEMA 4X rating, a nylon…

SKU 3G-OTH-176285

Brand
ASHCROFT
Item
Pressure Transmitter: 0 psi to 100 psi, 4 to 20mA DC
Category
Pressure Transmitters with 4-Pin Mini-DIN Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
G17MEK42M1100#
Series
G2
Type
4-Pin Mini-DIN Hirschmann G Series Connector
DC
4 to 20mA
Output
4 to 20mA DC
Accuracy
±0.5%
IP Rating
IP67
NEMA Rating
4X
Overpressure
2x Range
Burst Pressure
10x Range
Housing Material
Nylon
Process Connection Type
SAE
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT G2 Pressure Transmitter (0 psi to 100 psi) is a pressure transmitter with a 4-Pin Mini-DIN connector, offering a 4 to 20mA DC output. It features ±0.5% accuracy, an IP67 and NEMA 4X rating, a nylon housing, and an SAE process connection. Overpressure is 2x range, burst pressure is 10x range.

Frequently Asked Questions

What is the ASHCROFT G2 pressure transmitter used for?

The ASHCROFT G2 pressure transmitter measures pressure from 0 psi to 100 psi and outputs a 4 to 20mA DC signal. It is used in industrial applications requiring reliable pressure monitoring, such as hydraulic systems, pumps, and compressors, where its IP67 and NEMA 4X ratings protect against moisture and dust.

What are the specifications of the ASHCROFT G2 pressure transmitter?

The ASHCROFT G2 pressure transmitter (MPN G17MEK42M1100#) has a range of 0 psi to 100 psi, ±0.5% accuracy, 4 to 20mA DC output, and a 4-Pin Mini-DIN Hirschmann G Series connector. It features an IP67 and NEMA 4X rating, nylon housing, SAE process connection, overpressure of 2x range, and burst pressure of 10x range.

Where to buy the ASHCROFT G2 pressure transmitter worldwide?

3G Electric supplies the ASHCROFT G2 pressure transmitter worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we source and deliver this transmitter to meet your procurement needs.

How to install the ASHCROFT G2 pressure transmitter?

Install the ASHCROFT G2 pressure transmitter by connecting the SAE male process connection to a compatible port, ensuring a proper seal. Wire the 4-Pin Mini-DIN Hirschmann connector per the pinout for 4 to 20mA DC output. Avoid over-torquing and verify the pressure range does not exceed 2x range overpressure to prevent damage.

Used in

Common applications for ASHCROFT
Process control in chemical plants — ASHCROFT G2 series pressure transmitters with 4-20 mA output
Sanitary monitoring in food processing — ASHCROFT sanitary pressure transmitters with stainless steel fittings
Temperature measurement in oil and gas — ASHCROFT flanged thermowells rated to 1,000°F
Hydraulic system pressure monitoring — ASHCROFT G2 series transmitters with 1-5 V DC output
Hazardous location pressure sensing — ASHCROFT A2X explosion-proof transmitters with conduit connection
Steam system temperature protection — ASHCROFT threaded thermowells rated to 7,000 psi

ASHCROFT Products

3G Electric supplies ASHCROFT pressure transmitters with 4-pin mini-din connector. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
