ASHCROFT Pressure Transmitter: 0 psi to 30 psi, 4 to 20mA DC, Cable & Wire Leads - Pressure Transmitters with Cable & Wire Leads
ASHCROFTPressure Transmitters with Cable & Wire Leads

ASHCROFT Pressure Transmitter: 0 psi to 30 psi, 4 to 20mA DC, Cable & Wire Leads

The ASHCROFT G2 Pressure Transmitter (0 psi to 30 psi) is a pressure transmitter with cable and wire leads, offering a 4 to 20mA DC output. It features ±0.5% accuracy, an IP67 and NEMA 4X rating, a nylon housing, and…

SKU 3G-OTH-176430

Brand
ASHCROFT
Item
Pressure Transmitter: 0 psi to 30 psi, 4 to 20mA DC, Cable & Wire Leads
Category
Pressure Transmitters with Cable & Wire Leads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
G17MEK42F230#
Series
G2
Type
Cable & Wire Leads, IP67 /4X
DC
4 to 20mA
Output
4 to 20mA DC
Accuracy
±0.5%
Male SAE
7/16 in
IP Rating
IP67
NEMA Rating
4X
Overpressure
2x Range
Burst Pressure
10x Range
Housing Material
Nylon
Process Connection Type
SAE
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT G2 Pressure Transmitter (0 psi to 30 psi) is a pressure transmitter with cable and wire leads, offering a 4 to 20mA DC output. It features ±0.5% accuracy, an IP67 and NEMA 4X rating, a nylon housing, and a 7/16 in male SAE process connection. Overpressure capacity is 2x range, with burst pressure at 10x range.

Frequently Asked Questions

What is the ASHCROFT G2 pressure transmitter used for?

The ASHCROFT G2 pressure transmitter measures pressure from 0 psi to 30 psi and outputs a 4 to 20mA DC signal. It is used in industrial applications requiring reliable pressure monitoring, such as hydraulic systems, pumps, and compressors, where its IP67 and NEMA 4X ratings protect against moisture and dust.

What are the specifications of the ASHCROFT G2 pressure transmitter?

The ASHCROFT G2 pressure transmitter (MPN G17MEK42F230#) has a range of 0 psi to 30 psi, accuracy of ±0.5%, output of 4 to 20mA DC, and a 7/16 in male SAE connection. It features a nylon housing, IP67 and NEMA 4X ratings, overpressure of 2x range, and burst pressure of 10x range.

Where to buy the ASHCROFT G2 pressure transmitter worldwide?

You can source the ASHCROFT G2 pressure transmitter worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this model.

How to install the ASHCROFT G2 pressure transmitter?

Install the ASHCROFT G2 pressure transmitter by connecting the 7/16 in male SAE fitting to a compatible port. Use the cable and wire leads for 4 to 20mA DC wiring, ensuring proper polarity. Avoid exceeding 2x range overpressure. Follow standard industrial practices for sealing and environmental protection.
