ASHCROFT Pressure Transmitter: 0 psi to 100 psi, 4 to 20mA DC, Cable & Wire Leads - Pressure Transmitters with Cable & Wire Leads
ASHCROFTPressure Transmitters with Cable & Wire Leads

ASHCROFT Pressure Transmitter: 0 psi to 100 psi, 4 to 20mA DC, Cable & Wire Leads

The ASHCROFT G2 Pressure Transmitter (0 psi to 100 psi) is a pressure transmitter with cable and wire leads, featuring a 4 to 20mA DC output. It offers ±0.5% accuracy, an IP67 and NEMA 4X rating, and a nylon housing…

SKU 3G-OTH-176433

Brand
ASHCROFT
Item
Pressure Transmitter: 0 psi to 100 psi, 4 to 20mA DC, Cable & Wire Leads
Category
Pressure Transmitters with Cable & Wire Leads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
G17MEK42F2100#
Series
G2
Type
Cable & Wire Leads, IP67 /4X
DC
4 to 20mA
Output
4 to 20mA DC
Accuracy
±0.5%
Male SAE
7/16 in
IP Rating
IP67
NEMA Rating
4X
Overpressure
2x Range
Burst Pressure
10x Range
Housing Material
Nylon
Process Connection Type
SAE
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT G2 Pressure Transmitter (0 psi to 100 psi) is a pressure transmitter with cable and wire leads, featuring a 4 to 20mA DC output. It offers ±0.5% accuracy, an IP67 and NEMA 4X rating, and a nylon housing with a 7/16 in male SAE process connection. Overpressure is 2x range, burst pressure is 10x range, and no NIST-traceable calibration certificate is included.

Frequently Asked Questions

What is the ASHCROFT G2 pressure transmitter used for?

The ASHCROFT G2 pressure transmitter is used for industrial pressure measurement in hydraulic, pneumatic, and process control systems. Its 4 to 20mA DC output and IP67/NEMA 4X rating suit harsh environments. 3G Electric supplies this transmitter for worldwide applications.

What are the specifications of the ASHCROFT G2 pressure transmitter?

The ASHCROFT G2 pressure transmitter (MPN G17MEK42F2100#) has a range of 0 psi to 100 psi, ±0.5% accuracy, 4 to 20mA DC output, IP67 and NEMA 4X ratings, nylon housing, 7/16 in male SAE connection, overpressure 2x range, and burst pressure 10x range. No NIST-traceable calibration certificate is included.

Where to buy the ASHCROFT G2 pressure transmitter worldwide?

You can source the ASHCROFT G2 pressure transmitter from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the ASHCROFT G2 pressure transmitter?

Install the ASHCROFT G2 pressure transmitter by connecting the 7/16 in male SAE fitting to a compatible port, ensuring a leak-free seal. Wire the 4 to 20mA DC output per the wiring diagram. Avoid over-torquing the nylon housing. 3G Electric provides sourcing support for this transmitter.
