ASHCROFT Pressure Transmitter: 0 psi to 200 psi, 1 to 5V DC, Cable & Wire Leads - Pressure Transmitters with Cable & Wire Leads
ASHCROFTPressure Transmitters with Cable & Wire Leads

ASHCROFT Pressure Transmitter: 0 psi to 200 psi, 1 to 5V DC, Cable & Wire Leads

The ASHCROFT G2 Series Pressure Transmitter (0 psi to 200 psi) is a pressure transmitter with cable and wire leads, featuring a 1 to 5V DC output and a 1/8 in Male NPT process connection. It offers an accuracy of…

SKU 3G-OTH-176350

Brand
ASHCROFT
Item
Pressure Transmitter: 0 psi to 200 psi, 1 to 5V DC, Cable & Wire Leads
Category
Pressure Transmitters with Cable & Wire Leads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
G17M0115F2200#
Series
G2
Type
Cable & Wire Leads, IP67 /4X
DC
1 to 5V
Output
1 to 5V DC
Accuracy
±0.5%
Male NPT
1/8 in
IP Rating
IP67
NEMA Rating
4X
Overpressure
2x Range
Burst Pressure
10x Range
Housing Material
Nylon
Process Connection Type
NPT
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT G2 Series Pressure Transmitter (0 psi to 200 psi) is a pressure transmitter with cable and wire leads, featuring a 1 to 5V DC output and a 1/8 in Male NPT process connection. It offers an accuracy of ±0.5%, an overpressure of 2x Range, and a burst pressure of 10x Range, housed in a Nylon enclosure with IP67 and NEMA 4X ratings. This model (MPN G17M0115F2200#) does not include a NIST-traceable calibration certificate.

Frequently Asked Questions

What is the ASHCROFT G2 pressure transmitter used for?

The ASHCROFT G2 pressure transmitter measures 0 psi to 200 psi in industrial systems requiring a 1 to 5V DC output. It is suited for applications like pump monitoring, hydraulic controls, and process automation where a Nylon housing with IP67 and NEMA 4X ratings provides protection against moisture and dust.

What are the specifications of the ASHCROFT G17M0115F2200# pressure transmitter?

This ASHCROFT G2 transmitter has a 0 psi to 200 psi range, ±0.5% accuracy, 1 to 5V DC output, and a 1/8 in Male NPT connection. It features 2x Range overpressure, 10x Range burst pressure, Nylon housing, IP67 and NEMA 4X ratings, and no NIST-traceable calibration certificate included.

Where to buy the ASHCROFT G2 pressure transmitter worldwide?

3G Electric supplies the ASHCROFT G2 pressure transmitter (MPN G17M0115F2200#) to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this model.

How to install the ASHCROFT G2 pressure transmitter with cable leads?

Install the ASHCROFT G2 transmitter by applying thread sealant to the 1/8 in Male NPT connection and tightening to the process port. Connect the cable and wire leads to a 1 to 5V DC input device, ensuring polarity matches. Avoid over-torquing the Nylon housing to prevent damage.

Used in

Common applications for ASHCROFT
Process control in chemical plants — ASHCROFT G2 series pressure transmitters with 4-20 mA output
Sanitary monitoring in food processing — ASHCROFT sanitary pressure transmitters with stainless steel fittings
Temperature measurement in oil and gas — ASHCROFT flanged thermowells rated to 1,000°F
Hydraulic system pressure monitoring — ASHCROFT G2 series transmitters with 1-5 V DC output
Hazardous location pressure sensing — ASHCROFT A2X explosion-proof transmitters with conduit connection
Steam system temperature protection — ASHCROFT threaded thermowells rated to 7,000 psi

ASHCROFT Products

3G Electric supplies ASHCROFT pressure transmitters with cable & wire leads. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
