ASHCROFT Pressure Transmitter: 0 psi to 3,000 psi, 1 to 5V DC, Cable & Wire Leads - Pressure Transmitters with Cable & Wire Leads
ASHCROFTPressure Transmitters with Cable & Wire Leads

ASHCROFT Pressure Transmitter: 0 psi to 3,000 psi, 1 to 5V DC, Cable & Wire Leads

The ASHCROFT G2 Pressure Transmitter (0 psi to 3,000 psi) is a pressure transmitter with cable and wire leads, featuring a 1 to 5V DC output and ±0.5% accuracy. It has a nylon housing, IP67 and NEMA 4X ratings, a 1/8…

SKU 3G-OTH-176356

Brand
ASHCROFT
Item
Pressure Transmitter: 0 psi to 3,000 psi, 1 to 5V DC, Cable & Wire Leads
Category
Pressure Transmitters with Cable & Wire Leads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
G17M0115F23000#
Series
G2
Type
Cable & Wire Leads, IP67 /4X
DC
1 to 5V
Output
1 to 5V DC
Accuracy
±0.5%
Male NPT
1/8 in
IP Rating
IP67
NEMA Rating
4X
Overpressure
2x Range
Burst Pressure
5x Range
Housing Material
Nylon
Process Connection Type
NPT
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT G2 Pressure Transmitter (0 psi to 3,000 psi) is a pressure transmitter with cable and wire leads, featuring a 1 to 5V DC output and ±0.5% accuracy. It has a nylon housing, IP67 and NEMA 4X ratings, a 1/8 in Male NPT process connection, and overpressure of 2x range with burst pressure of 5x range.

Frequently Asked Questions

What is the ASHCROFT G2 pressure transmitter used for?

The ASHCROFT G2 pressure transmitter measures pressure from 0 psi to 3,000 psi and outputs a 1 to 5V DC signal. It is used in industrial applications requiring ±0.5% accuracy, IP67/NEMA 4X protection, and a nylon housing. Typical uses include hydraulic systems, pumps, and process control where reliable pressure monitoring is needed.

What are the specifications of the ASHCROFT G2 pressure transmitter?

The ASHCROFT G2 pressure transmitter (MPN G17M0115F23000#) has a range of 0 psi to 3,000 psi, accuracy ±0.5%, output 1 to 5V DC, IP67 and NEMA 4X ratings, overpressure 2x range, burst pressure 5x range, nylon housing, and a 1/8 in Male NPT connection. It does not include a NIST-traceable calibration certificate.

Where to buy the ASHCROFT G2 pressure transmitter worldwide?

3G Electric supplies the ASHCROFT G2 pressure transmitter worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time. We source and deliver this transmitter to meet your project requirements.

How to install the ASHCROFT G2 pressure transmitter?

Install the ASHCROFT G2 pressure transmitter by connecting the 1/8 in Male NPT process connection to a compatible port. Use the cable and wire leads for 1 to 5V DC output. Ensure the housing is sealed to maintain IP67/NEMA 4X protection. Avoid exceeding 2x range overpressure. Follow standard wiring practices for industrial transmitters.

Used in

Common applications for ASHCROFT
Process control in chemical plants — ASHCROFT G2 series pressure transmitters with 4-20 mA output
Sanitary monitoring in food processing — ASHCROFT sanitary pressure transmitters with stainless steel fittings
Temperature measurement in oil and gas — ASHCROFT flanged thermowells rated to 1,000°F
Hydraulic system pressure monitoring — ASHCROFT G2 series transmitters with 1-5 V DC output
Hazardous location pressure sensing — ASHCROFT A2X explosion-proof transmitters with conduit connection
Steam system temperature protection — ASHCROFT threaded thermowells rated to 7,000 psi

ASHCROFT Products

3G Electric supplies ASHCROFT pressure transmitters with cable & wire leads. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
