ASHCROFT Gauge/seal assembly: 0 psi to 600 psi - Acid Leak Detection Gauges
ASHCROFTAcid Leak Detection Gauges

ASHCROFT Gauge/seal assembly: 0 psi to 600 psi

The ASHCROFT 45ALD1P1PP04S600# is an acid leak detection gauge/seal assembly with a 0 psi to 600 psi primary scale. It features ±1.00% accuracy, a phenolic case with silicone fill, and a stem-mount design. The sensor…

SKU 3G-OTH-174542

Brand
ASHCROFT
Item
Gauge/seal assembly: 0 psi to 600 psi
Category
Acid Leak Detection Gauges
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
45ALD1P1PP04S600#
Type
600 psi Primary Scale Pressure Measurement - Max
Accuracy
±1.00%
Case Liquid
Silicone
Case Material
Phenolic
Mounting Type
Stem-Mount
Sensor Material
Monel
Socket Material
Monel
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT 45ALD1P1PP04S600# is an acid leak detection gauge/seal assembly with a 0 psi to 600 psi primary scale. It features ±1.00% accuracy, a phenolic case with silicone fill, and a stem-mount design. The sensor and socket are constructed from Monel.

Frequently Asked Questions

What is the ASHCROFT 45ALD1P1PP04S600# acid leak detection gauge used for?

The ASHCROFT 45ALD1P1PP04S600# is used to detect acid leaks in industrial processes by measuring pressure from 0 psi to 600 psi. Its Monel sensor and socket resist corrosive media, making it suitable for chemical plants, refineries, and other harsh environments where acid exposure is a concern.

What are the specifications of the ASHCROFT 45ALD1P1PP04S600# gauge/seal assembly?

The ASHCROFT 45ALD1P1PP04S600# has a 0 psi to 600 psi primary scale with ±1.00% accuracy. It features a phenolic case filled with silicone, a stem-mount design, and Monel sensor and socket materials. The manufacturer part number is 45ALD1P1PP04S600#.

Where to buy the ASHCROFT 45ALD1P1PP04S600# in worldwide?

3G Electric supplies the ASHCROFT 45ALD1P1PP04S600# worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this acid leak detection gauge/seal assembly.

How to install the ASHCROFT 45ALD1P1PP04S600# stem-mount gauge?

Install the ASHCROFT 45ALD1P1PP04S600# by threading the stem into a compatible process connection. Use appropriate sealant on threads to prevent leaks. Ensure the gauge is mounted vertically for accurate readings. Avoid over-torquing the stem to prevent damage to the Monel socket.
