BRAD HARRISON Cordset: 1"-16 Male Straight x Bare Wire, 8 Pins, Yellow, PVC, 1 ft Cable Lg - Single-Ended Cordsets
BRAD HARRISONSingle-Ended Cordsets

BRAD HARRISON Cordset: 1"-16 Male Straight x Bare Wire, 8 Pins, Yellow, PVC, 1 ft Cable Lg

The BRAD HARRISON Cordset: 1"-16 Male Straight x Bare Wire is a single-ended cordset with 8 pins, a yellow PVC jacket, and a 1 ft cable length. It features a 16 AWG wire size, an IP67 rating, and a maximum current of…

SKU 3G-OTH-47006

Brand
BRAD HARRISON
Item
Cordset: 1"-16 Male Straight x Bare Wire, 8 Pins, Yellow, PVC, 1 ft Cable Lg
Category
Single-Ended Cordsets
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

BRAD HARRISON
Manufacturer Part Number
2R8006A20A120
Type
Yellow, PVC
Pins
8
Cable Lg
1 ft
IP Rating
IP67
Wire Size
16 AWG
Max Current (A)
7 A
Cable Jacket Color
Yellow
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

BRAD HARRISON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The BRAD HARRISON Cordset: 1"-16 Male Straight x Bare Wire is a single-ended cordset with 8 pins, a yellow PVC jacket, and a 1 ft cable length. It features a 16 AWG wire size, an IP67 rating, and a maximum current of 7 A.

Frequently Asked Questions

What is the BRAD HARRISON Cordset 2R8006A20A120 used for?

This single-ended cordset connects industrial sensors or actuators to control systems. Its 1"-16 male straight connector and 8-pin configuration suit factory automation, packaging machinery, and material handling equipment where a reliable, watertight connection is needed.

What are the specifications of the BRAD HARRISON Cordset 2R8006A20A120?

The cordset has 8 pins, a 1 ft cable length, 16 AWG wire, and a yellow PVC jacket. It is rated IP67 for dust and water ingress protection, with a maximum current of 7 A. The male straight connector is 1"-16 thread. BRAD HARRISON is the OEM brand.

Where to buy the BRAD HARRISON Cordset 2R8006A20A120 worldwide?

3G Electric supplies the BRAD HARRISON Cordset 2R8006A20A120 to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time; we source and deliver this single-ended cordset globally.

How to select the right BRAD HARRISON cordset for an application?

Match the connector thread size (1"-16), pin count (8), and cable length to your device. Verify the IP rating (IP67) suits the environment, and ensure the wire gauge (16 AWG) and current rating (7 A) meet your load. BRAD HARRISON offers various configurations for industrial automation.

Used in

Common applications for BRAD HARRISON
Factory automation — BRAD HARRISON M12 cordsets (e.g., SKU 2EPL5) connect proximity sensors to PLC I/O modules in assembly lines.
Material handling — BRAD HARRISON 7/8"-16 cordsets (SKU 5AA48) power solenoid valves on conveyor systems.
Process control — BRAD HARRISON Micro M12 receptacles (SKU 2EPG9) interface with pressure transmitters in chemical plants.
Packaging machinery — BRAD HARRISON M12 right-angle cordsets (SKU 2EPH8) connect photoelectric sensors in tight spaces.
Washdown environments — BRAD HARRISON IP68-rated cordsets (SKU 2EPN1) are used in food processing equipment requiring frequent cleaning.
Robotics — BRAD HARRISON M12 male cordsets (SKU 2ENL8) provide signal connections for end-of-arm tooling.

BRAD HARRISON Products

3G Electric supplies BRAD HARRISON single-ended cordsets. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
