Inpro VD2 LR-2.2 low pressure pump
Inpro VD2 LR-2.2 is a low-pressure oil burner fuel unit with integral pressure regulation, delivering 3500 rpm operation and maximum 2 bar return-line pressure. Features nylon mesh strainer rated 150µ and G1/8"…
SKU 3G-CBM-00100
Also listed as: LR 22 · LR-22
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
Inpro VD2 LR-2.2 is a low-pressure oil burner fuel unit with integral pressure regulation, delivering 3500 rpm operation and maximum 2 bar return-line pressure. Features nylon mesh strainer rated 150µ and G1/8" nozzle port, fitting heating and combustion applications requiring reliable fuel supply control.
Frequently Asked Questions
What is the Inpro VD2 LR-2.2 low pressure pump used for?
The Inpro VD2 LR-2.2 is a low-pressure oil burner fuel unit designed for pumping oil in high-pressure oil burners and transfer pump applications. It is suitable for heating and combustion systems requiring reliable fuel supply control, including one or two pipe systems.
What are the specifications of the Inpro VD2 LR-2.2?
The Inpro VD2 LR-2.2 features a nylon mesh strainer rated 150µ, G1/8" nozzle port, G1/4" inlet and return ports, 32 mm hub diameter, 8 mm shaft diameter, and operates at 3500 rpm with a maximum return-line pressure of 2 bar. It complies with EN 225 and ISO 228/1 standards.
Where to buy the Inpro VD2 LR-2.2 in Singapore?
You can source the Inpro VD2 LR-2.2 low pressure pump through 3G Electric in Singapore. We handle logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on availability.
How to install the Inpro VD2 LR-2.2 fuel unit?
Install the Inpro VD2 LR-2.2 by connecting the suction, return, and nozzle ports per the manufacturer's guidelines. Ensure the shaft aligns with the burner coupling and the strainer is clean. For two-pipe systems, verify the pressure regulating screw adjustment. Always follow standard safety practices for oil burner components.
Used in
Common applications for InproInpro Products
3G Electric supplies Inpro oil supply. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
