ELVSolenoid Valves

ELV Steam solenoid valve D 1"1/2

ELV steam solenoid valve with DN1½ connection and 35 mm passage diameter for steam system control. Operates across 0.5–10 bar with maximum differential pressure rating of 25 bar, suitable for industrial steam…

SKU 3G-CBM-03267

Also listed as: ELV 35012 · ELV-35012

Brand

ELV

Item

Steam solenoid valve D 1"1/2

Local availability & support — Singapore

Local office: 20 Woodlands Link #09-05, Singapore 738733
Phone: +65 8878 8355
Delivery: Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
Payment: Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
Ships to: Singapore

Technical Specifications

ELV

fluid

steam

cv value

26

connection

1"

connection size

1"1/2

max pressure bar

10

passage diameter mm

35

operating pressure bar

0.5 ~ 10

max differential pressure bar

25

Datasheet Content

Electrovannes bronze NF vapeur                                                    Code

      Electrovanne vapeur 3/8”                                                                           ELV35002

      Electrovanne vapeur 1/2”                                                                           ELV35004

      Electrovanne vapeur 3/4”                                                                           ELV35006

      Electrovanne vapeur 1”                                                                             ELV35008

      Electrovanne vapeur 1”1/4                                                                          ELV35010

      Electrovanne vapeur 1”1/2                                                                          3G-CBM-03267

      Caractéristiques techniques
                  Modèle             ELV35002   ELV35004   ELV35006     ELV35008       ELV35010   3G-CBM-03267    ELV35014
      Diamètre Raccord                3/8”       1/2”       3/4”           1”          1”1/4      1”1/2         2”
      Diamètre passage               15mm       15mm       20mm          25mm          35mm       35mm         50mm
      Pression différentielle max.     25         25         25            25            25         25          25
      Valeur CV                        4.5        4.5        9.3          13.2           16         26          48
      Dim. A mm                        75         75         85           100           120        120         150
      Dim. C mm                       129        129        141           148           168        168         190
      Viscosité fluide                                             Moins de 50 CST
      Fluide                                                             Vapeur
      Pression fonctionnement                                         0.5 ~ 10 bar
      Pression maxi                                                      10 bar
      Température maxi                                                5°C ~ 180°C
      Tension                                                      +/- 10% - AC230V
      Matériel corps                                                     Bronze
      Membrane                                                            Teflon
      Mode opération                                                  Action directe
      Type                                                        Normalement fermée

      PIÈCES DE RECHANGES POUR VANNES
                  Modèle             ELV35002   ELV35004   ELV35006     ELV35008       ELV35010   3G-CBM-03267    ELV35014
      Référence bobine 220 V         ELV80515   ELV80515   ELV80515     ELV80515       ELV80515   ELV80515    ELV80515
      Référence bobine 110 V            -          -          -             -             -          -           -
      Référence bobine AC 48 V          -          -          -             -             -          -           -
      Référence bobine AC 24 V          -          -          -             -             -          -           -
      Référence bobine AC 12 V          -          -          -             -             -          -           -
      Référence bobine DC 24 V       ELV81515   ELV81515   ELV81515     ELV81515       ELV81515   ELV81515    ELV81515
      Référence bobine DC 12 V       ELV81530   ELV81530   ELV81530     ELV81530       ELV81530   ELV81530    ELV81530
      Référence membrane NBR            -          -          -             -             -          -           -
      Référence membrane EPDM           -          -          -             -             -          -           -
      Référence membrane VITON          -          -          -             -             -          -           -

254
BRASS STREAM VALVES
2/2-Way Pilot Operated Piston Solenoid Valve . Normally closed

                                                                 1/4
2/2-Way Pilot Operated Piston Solenoid Valve . Normally closed

                                                     ELV35004

                                                     ELV35006

                                                     ELV35008

                                                     ELV35010

                                                      3G-CBM-03267

                                                                 2/4
                              1/4

        INOX STREAM VALVES
2/2-Way Pilot Operated Piston Solenoid Valve . Normally closed

                                                     ELV40002

                                                     ELV40004

                                                     ELV40006

                                                     ELV40008

                                                                 3/4
2/2-Way Pilot Operated Piston Solenoid Valve . Normally closed

                                                                 4/4

Technical Documents

(2)

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

ELV Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

What is the ELV steam solenoid valve D 1"1/2 used for?

The ELV steam solenoid valve D 1"1/2 is used to control steam flow in industrial steam distribution and process automation systems. It operates with steam at 0.5–10 bar and handles a maximum differential pressure of 25 bar, making it suitable for applications requiring reliable on/off steam control.

What are the specifications of the ELV steam solenoid valve D 1"1/2?

The ELV steam solenoid valve D 1"1/2 has a 1"1/2 connection, 35 mm passage diameter, Cv value of 26, and operates from 0.5 to 10 bar with a maximum differential pressure of 25 bar. It is a normally closed, direct-acting bronze valve with a Teflon membrane, rated for steam up to 180 °C.

Where to buy the ELV steam solenoid valve D 1"1/2 in Singapore?

You can source the ELV steam solenoid valve D 1"1/2 through 3G Electric in Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time on this ELV valve for your steam control application.

How to install the ELV steam solenoid valve D 1"1/2?

Install the ELV steam solenoid valve D 1"1/2 with the flow direction matching the arrow on the body. Use appropriate thread sealant on the 1"1/2 connections and ensure the coil voltage (AC 230 V or DC 24 V) matches your supply. Mount the valve with the coil upright to prevent condensation damage.
