CHAINFLEX Control Cable: 16 AWG, 7 Conductors, 100 ft, PUR Jacket - Continuous Flexing Control Cables
CHAINFLEXContinuous Flexing Control Cables

CHAINFLEX Control Cable: 16 AWG, 7 Conductors, 100 ft, PUR Jacket

The CHAINFLEX Control Cable (SKU 24C023, MPN CF77-UL-15-07-100) is a continuous flexing control cable from the Chainflex series. It features 16 AWG, 7 copper conductors with a PUR jacket, rated at 1,000 V, and…

SKU 3G-OTH-53260

Brand
CHAINFLEX
Item
Control Cable: 16 AWG, 7 Conductors, 100 ft, PUR Jacket
Category
Continuous Flexing Control Cables
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

CHAINFLEX
Manufacturer Part Number
CF77-UL-15-07-100
Series
Chainflex
Standards
cRUus
Cable Series
CF77-UL
Product Type
Control Cable
Includes Ground
Yes
Conductor Material
Copper
Conductor Color Code
Black with White Numbers
Resistance Properties
Notch Resistance
Conductor Configuration
Single
Minimum Bend Radius Factor - Fixed
4 x OD
Minimum Bend Radius Factor - E-Chain
6.8 x OD
Minimum Bend Radius Factor - Flexible
5 x OD
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

CHAINFLEX Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CHAINFLEX Control Cable (SKU 24C023, MPN CF77-UL-15-07-100) is a continuous flexing control cable from the Chainflex series. It features 16 AWG, 7 copper conductors with a PUR jacket, rated at 1,000 V, and includes a ground conductor. The cable meets cRUus standards and offers notch resistance, with minimum bend radius factors of 4 x OD for fixed, 5 x OD for flexible, and 6.8 x OD for e-chain applications.

Frequently Asked Questions

What is the CHAINFLEX Control Cable used for?

The CHAINFLEX Control Cable is designed for continuous flexing applications in automated machinery, robotics, and cable carriers (e-chains). It provides reliable signal and control transmission in dynamic environments where cables must withstand repeated bending and movement.

What are the specifications of the CHAINFLEX Control Cable CF77-UL-15-07-100?

This cable has 16 AWG, 7 copper conductors with a PUR jacket, rated at 1,000 V. It includes a ground conductor and meets cRUus standards. Minimum bend radius factors are 4 x OD for fixed, 5 x OD for flexible, and 6.8 x OD for e-chain applications. It offers notch resistance.

Where to buy CHAINFLEX Control Cable in worldwide?

3G Electric supplies the CHAINFLEX Control Cable worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us to source this cable for your application.

How to select the right CHAINFLEX Control Cable for an e-chain application?

For e-chain use, ensure the cable's minimum bend radius factor (6.8 x OD for this model) matches your carrier's specifications. Verify voltage rating (1,000 V), conductor count (7), and jacket material (PUR) for abrasion resistance. Always consult the Chainflex series guidelines for proper cable selection.
