CHAINFLEX Control Cable: 16 AWG, 12 Conductors, 25 ft, PVC Jacket - Continuous Flexing Control Cables
CHAINFLEXContinuous Flexing Control Cables

CHAINFLEX Control Cable: 16 AWG, 12 Conductors, 25 ft, PVC Jacket

The CHAINFLEX Control Cable (SKU 2TZP9) is a continuous flexing control cable from the Chainflex CF6 series, featuring 16 AWG, 12 conductors, a PVC jacket, and a 600 V rating. It includes a ground conductor, copper…

SKU 3G-OTH-49514

Brand
CHAINFLEX
Item
Control Cable: 16 AWG, 12 Conductors, 25 ft, PVC Jacket
Category
Continuous Flexing Control Cables
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

CHAINFLEX
Manufacturer Part Number
CF6-15-12-25
Series
Chainflex
Standards
CE
Cable Series
CF6
Product Type
Control Cable
Includes Ground
Yes
Conductor Material
Copper
Conductor Color Code
Black with White Numbers
Resistance Properties
Heat Resistant
Conductor Configuration
Single
Minimum Bend Radius Factor - Fixed
4 x OD
Minimum Bend Radius Factor - E-Chain
6.8 x OD
Minimum Bend Radius Factor - Flexible
5 x OD
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

CHAINFLEX Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CHAINFLEX Control Cable (SKU 2TZP9) is a continuous flexing control cable from the Chainflex CF6 series, featuring 16 AWG, 12 conductors, a PVC jacket, and a 600 V rating. It includes a ground conductor, copper conductors with black/white number coding, and is heat resistant. The cable meets CE standards and offers minimum bend radius factors of 4 x OD for fixed, 5 x OD for flexible, and 6.8 x OD for e-chain applications.

Frequently Asked Questions

What is a CHAINFLEX CF6 control cable used for?

The CHAINFLEX CF6 control cable is designed for continuous flexing applications in industrial automation, robotics, and cable carriers (e-chains). It reliably transmits control signals in machinery where repeated bending occurs, such as in assembly lines or packaging equipment.

What are the specifications of the CHAINFLEX CF6-15-12-25 cable?

This CHAINFLEX cable has 12 conductors of 16 AWG copper wire, a PVC jacket, and a 600 V rating. It includes a ground conductor, is heat resistant, and meets CE standards. Minimum bend radius factors are 4 x OD fixed, 5 x OD flexible, and 6.8 x OD for e-chain use.

Where to buy CHAINFLEX control cables worldwide?

3G Electric supplies CHAINFLEX control cables worldwide, handling full logistics and customs clearance for global delivery. As a sourcing partner, we provide genuine CHAINFLEX products like the CF6-15-12-25 to industrial buyers across multiple regions.

How to select the right CHAINFLEX cable for continuous flexing?

Select a CHAINFLEX cable based on conductor count, AWG size, voltage rating, and bend radius requirements for your e-chain or moving application. For the CF6 series, ensure the minimum bend radius factors (fixed 4 x OD, flexible 5 x OD, e-chain 6.8 x OD) match your installation geometry.

Used in

Common applications for CHAINFLEX
Automated assembly lines — Chainflex CF10 control cables for signal transmission in cable carriers
Robotic arms — Chainflex CF280ULH servo motor cables for power and feedback in high-flex joints
Material handling conveyors — Chainflex CF78-UL control cables with PUR jacket for oil resistance
CNC machining centers — Chainflex CF9-UL control cables rated at 1,000 V for spindle and axis control
Packaging machinery — Chainflex CFBUS-PVC-021 bus cables for CAN-Bus communication in continuous motion
Automotive manufacturing — Chainflex CF2 control cables with UV-resistant PUR jacket for outdoor gantry systems
