CHAINFLEX Control Cable: 16 AWG, 5 Conductors, 100 ft, PVC Jacket - Continuous Flexing Control Cables
CHAINFLEXContinuous Flexing Control Cables

CHAINFLEX Control Cable: 16 AWG, 5 Conductors, 100 ft, PVC Jacket

The CHAINFLEX CF6-15-05-100 is a continuous flexing control cable from the Chainflex series, featuring 16 AWG, 5 conductors, a PVC jacket, and a 600 V rating. It includes a ground conductor, is made of copper with a…

SKU 3G-OTH-48755

Brand
CHAINFLEX
Item
Control Cable: 16 AWG, 5 Conductors, 100 ft, PVC Jacket
Category
Continuous Flexing Control Cables
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

CHAINFLEX
Manufacturer Part Number
CF6-15-05-100
Series
Chainflex
Standards
CE
Cable Series
CF6
Product Type
Control Cable
Includes Ground
Yes
Conductor Material
Copper
Conductor Color Code
Black with White Numbers
Resistance Properties
Oil and Grease Resistant
Conductor Configuration
Single
Minimum Bend Radius Factor - Fixed
4 x OD
Minimum Bend Radius Factor - E-Chain
6.8 x OD
Minimum Bend Radius Factor - Flexible
5 x OD
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

CHAINFLEX Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CHAINFLEX CF6-15-05-100 is a continuous flexing control cable from the Chainflex series, featuring 16 AWG, 5 conductors, a PVC jacket, and a 600 V rating. It includes a ground conductor, is made of copper with a single conductor configuration, and is oil and grease resistant. The cable meets CE standards and has minimum bend radius factors of 4 x OD for fixed installation, 5 x OD for flexible use, and 6.8 x OD for e-chain applications.

Frequently Asked Questions

What is the CHAINFLEX CF6-15-05-100 control cable used for?

The CHAINFLEX CF6-15-05-100 is a continuous flexing control cable designed for automated machinery, robotics, and cable carrier (e-chain) applications. Its oil- and grease-resistant PVC jacket and 600 V rating make it suitable for industrial environments requiring repeated bending without failure.

What are the specifications of the CHAINFLEX CF6-15-05-100?

This CHAINFLEX cable has 16 AWG, 5 conductors with a ground, copper single conductors, and a PVC jacket rated at 600 V. Minimum bend radius factors are 4 x OD fixed, 5 x OD flexible, and 6.8 x OD for e-chain. It meets CE standards and is oil and grease resistant.

Where to buy the CHAINFLEX CF6-15-05-100 worldwide?

3G Electric supplies the CHAINFLEX CF6-15-05-100 control cable worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this continuous flexing cable.

How to select the right CHAINFLEX cable for e-chain applications?

For e-chain applications, ensure the cable's minimum bend radius factor (6.8 x OD for this CHAINFLEX model) matches your carrier's bend radius. Also verify conductor count, AWG, voltage rating (600 V), and resistance to oils and grease. Always consult the manufacturer's installation guidelines for continuous flexing.

Used in

Common applications for CHAINFLEX
Automated assembly lines — Chainflex CF10 control cables for signal transmission in cable carriers
Robotic arms — Chainflex CF280ULH servo motor cables for power and feedback in high-flex joints
Material handling conveyors — Chainflex CF78-UL control cables with PUR jacket for oil resistance
CNC machining centers — Chainflex CF9-UL control cables rated at 1,000 V for spindle and axis control
Packaging machinery — Chainflex CFBUS-PVC-021 bus cables for CAN-Bus communication in continuous motion
Automotive manufacturing — Chainflex CF2 control cables with UV-resistant PUR jacket for outdoor gantry systems
