Dayton Cabinet Exhaust Fan: Belt Drive, 36 in Blade, 1 1/2 hp, Totally Enclosed Air Over - Cabinet Exhaust Fans
DaytonCabinet Exhaust Fans

Dayton Cabinet Exhaust Fan: Belt Drive, 36 in Blade, 1 1/2 hp, Totally Enclosed Air Over

The DAYTON Cabinet Exhaust Fan (MPN 1AHD2) is a belt-drive cabinet exhaust fan with a 36-inch blade and 1 1/2 hp motor. It features a Totally Enclosed Air Over design and delivers 14,148 cfm. The unit ships fully…

SKU 3G-OTH-81414

Brand
Dayton
Item
Cabinet Exhaust Fan: Belt Drive, 36 in Blade, 1 1/2 hp, Totally Enclosed Air Over
Category
Cabinet Exhaust Fans
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
1AHD2
Type
1 1/2 hp, Totally Enclosed Air Over, 14,148 cfm
Blade
36 in
Assembly
Ships Fully Assembled
Nameplate Voltage
208-230/460V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Cabinet Exhaust Fan (MPN 1AHD2) is a belt-drive cabinet exhaust fan with a 36-inch blade and 1 1/2 hp motor. It features a Totally Enclosed Air Over design and delivers 14,148 cfm. The unit ships fully assembled and operates on 208-230/460V AC.

Frequently Asked Questions

What is the DAYTON Cabinet Exhaust Fan used for?

The DAYTON Cabinet Exhaust Fan (MPN 1AHD2) is used for high-volume air removal in industrial and commercial facilities such as warehouses, factories, and assembly plants. Its belt-drive design and 14,148 cfm capacity make it suitable for exhausting heat, fumes, and airborne contaminants from large indoor spaces.

What are the specifications of the DAYTON Cabinet Exhaust Fan?

The DAYTON Cabinet Exhaust Fan (MPN 1AHD2) has a 36-inch blade, a 1 1/2 hp motor, and a Totally Enclosed Air Over design. It delivers 14,148 cfm and operates on 208-230/460V AC. The unit ships fully assembled for easier installation.

Where to buy the DAYTON Cabinet Exhaust Fan worldwide?

You can source the DAYTON Cabinet Exhaust Fan (MPN 1AHD2) through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the DAYTON Cabinet Exhaust Fan?

The DAYTON Cabinet Exhaust Fan ships fully assembled, simplifying installation. Mount the unit securely on a level surface or roof curb, connect the 208-230/460V AC power supply per local codes, and ensure the belt drive is properly tensioned. Always follow the manufacturer's manual for safe operation.
