Dayton Brake: Double C-Face Magnetic Disc Brake, 208-230/460V AC, 208-230/460V AC
The DAYTON Double C-Face Magnetic Disc Brake (SKU 2LYT8) is a dripproof brake designed for use with single and three phase general purpose C-face motors. It mounts on NEMA C-face flanges on motors and gear reducers…
SKU 3G-OTH-114789
Need installation or engineering help?
Ask a question
Product Description
The DAYTON Double C-Face Magnetic Disc Brake (SKU 2LYT8) is a dripproof brake designed for use with single and three phase general purpose C-face motors. It mounts on NEMA C-face flanges on motors and gear reducers, operates at 208-230/460V AC, and is rated for 2 hp at 1725 RPM. The unit includes hardware for installation.
Frequently Asked Questions
What is the DAYTON Double C-Face Magnetic Disc Brake used for?
The DAYTON Double C-Face Magnetic Disc Brake is used to provide braking torque on single and three phase general purpose C-face motors. It mounts on NEMA C-face flanges on motors and gear reducers, making it suitable for industrial machinery requiring controlled stopping.
What are the specifications of the DAYTON 2LYT8 brake?
The DAYTON 2LYT8 is a dripproof, double C-face magnetic disc brake rated for 2 hp at 1725 RPM. It operates at 208-230/460V AC and includes mounting hardware. The enclosure is dripproof, and it is designed for use with NEMA C-face flanges on motors and gear reducers.
Where to buy the DAYTON 2LYT8 brake in worldwide?
You can source the DAYTON 2LYT8 brake through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide locations. Contact us for availability and lead time on this part.
How to install the DAYTON Double C-Face Magnetic Disc Brake?
Install the DAYTON brake by mounting it directly onto the NEMA C-face flange of your motor or gear reducer using the provided hardware. Ensure the brake is aligned with the motor shaft and that the electrical supply matches the 208-230/460V AC rating. Follow standard industrial safety practices during installation.
