Dayton Brake: C-Face Magnetic Disc, 115/208-230V AC, 115/208-230V AC, 115/208-230V AC
The DAYTON C-Face Magnetic Disc Brake (MPN 3M366) is a dripproof brake for use with single-phase motors or when wired per instructions. It is rated at 3 hp @ 3450 RPM and mounts on a NEMA C Face motor or between the…
SKU 3G-OTH-114110
Need installation or engineering help?
Ask a question
Product Description
The DAYTON C-Face Magnetic Disc Brake (MPN 3M366) is a dripproof brake for use with single-phase motors or when wired per instructions. It is rated at 3 hp @ 3450 RPM and mounts on a NEMA C Face motor or between the motor and reducer. The brake operates on 115/208-230V AC.
Frequently Asked Questions
What is the DAYTON C-Face Magnetic Disc Brake used for?
The DAYTON C-Face Magnetic Disc Brake (3M366) is used to stop or hold a load on single-phase motors or when wired per instructions. It mounts on a NEMA C Face motor or between the motor and reducer, making it suitable for industrial machinery requiring reliable braking at 3 hp @ 3450 RPM.
What are the specifications of the DAYTON 3M366 brake?
The DAYTON 3M366 brake is a dripproof C-Face magnetic disc type rated at 3 hp @ 3450 RPM. It operates on 115/208-230V AC and mounts on a NEMA C Face motor or between the motor and reducer. It is designed for use with single-phase motors or when wired per instructions.
Where to buy the DAYTON 3M366 brake worldwide?
3G Electric supplies the DAYTON 3M366 C-Face Magnetic Disc Brake worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this brake to your facility. Contact us for availability and lead time on this dripproof brake for single-phase motor applications.
How to install a DAYTON C-Face Magnetic Disc Brake?
Mount the DAYTON 3M366 brake on a NEMA C Face motor or between the motor and reducer. Wire per the manufacturer's instructions for single-phase motors. Ensure the brake is securely fastened and the electrical supply matches the 115/208-230V AC rating. Always follow generic best practices for magnetic disc brake installation.
