Dayton Brake: C-Face Magnetic Disc, 115/208-230V AC - Washdown Brakes
DaytonWashdown Brakes

Dayton Brake: C-Face Magnetic Disc, 115/208-230V AC

The DAYTON Brake: C-Face Magnetic Disc is a washdown brake with a totally enclosed enclosure type. It is rated for 3 hp @ 3450 RPM and mounts between motor and reducer, designed for use with a 140TC NEMA motor frame…

SKU 3G-OTH-112404

Brand
Dayton
Item
Brake: C-Face Magnetic Disc, 115/208-230V AC
Category
Washdown Brakes
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
1L389
Type
110/208-220V AC @ 50 Hz/115/208-230V AC @ 60 Hz
AC
115/208-230V
For Use With
When Wired per Instructions
Enclosure Type
Totally Enclosed
Horsepower @ RPM
3 hp @ 3450 RPM
Clutch/Brake Type
C-Face Magnetic Disc
Mounting Location
Between Motor and Reducer
Motor Frame Designation
140TC NEMA
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Brake: C-Face Magnetic Disc is a washdown brake with a totally enclosed enclosure type. It is rated for 3 hp @ 3450 RPM and mounts between motor and reducer, designed for use with a 140TC NEMA motor frame. The unit operates on 115/208-230V AC (60 Hz) or 110/208-220V AC (50 Hz).

Frequently Asked Questions

What is the DAYTON C-Face Magnetic Disc brake used for?

The DAYTON C-Face Magnetic Disc brake is a washdown brake used to stop or hold a motor load in industrial applications. It mounts between a motor and reducer, typically on a 140TC NEMA frame, and is suitable for environments requiring a totally enclosed enclosure.

What are the specifications of the DAYTON 1L389 brake?

The DAYTON 1L389 brake is a C-Face Magnetic Disc type with a totally enclosed enclosure. It is rated for 3 hp at 3450 RPM, operates on 115/208-230V AC at 60 Hz or 110/208-220V AC at 50 Hz, and mounts between motor and reducer for a 140TC NEMA frame.

Where to buy the DAYTON 1L389 brake worldwide?

You can source the DAYTON 1L389 brake through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring the brake reaches your facility reliably.

How to install the DAYTON C-Face Magnetic Disc brake?

Install the DAYTON brake between the motor and reducer, aligning the C-face mounting. Wire per the provided instructions for 115/208-230V AC (60 Hz) or 110/208-220V AC (50 Hz). Ensure the motor frame is 140TC NEMA and the enclosure remains sealed for washdown environments.
