Dayton Brake: Double C-Face Magnetic Disc Brake, 115/208-230V AC, 115/208-230V AC - Washdown Brakes
DaytonWashdown Brakes

Dayton Brake: Double C-Face Magnetic Disc Brake, 115/208-230V AC, 115/208-230V AC

The DAYTON Double C-Face Magnetic Disc Brake (SKU 2LYU7) is a totally enclosed washdown brake designed for use with single and three phase BISSC and stainless steel C-Face motors in food washdown applications. It…

SKU 3G-OTH-112434

Brand
Dayton
Item
Brake: Double C-Face Magnetic Disc Brake, 115/208-230V AC, 115/208-230V AC
Category
Washdown Brakes
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
2LYU7
Type
Totally Enclosed
AC
115/208-230V
Includes
Hardware
For Use With
Single and Three Phase BISSC and Stainless Steel C-Face Motors Used in Food Washdown Applications
Enclosure Type
Totally Enclosed
Horsepower @ RPM
3 hp @ 1725 RPM
Clutch/Brake Type
Double C-Face Magnetic Disc Brake
Mounting Location
NEMA C-Face Flanges on Motors and Gear Reducers
Motor Frame Designation
56C/140TC NEMA/IEC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Double C-Face Magnetic Disc Brake (SKU 2LYU7) is a totally enclosed washdown brake designed for use with single and three phase BISSC and stainless steel C-Face motors in food washdown applications. It mounts on NEMA C-Face flanges on motors and gear reducers, with a motor frame designation of 56C/140TC NEMA/IEC. The brake operates at 3 hp @ 1725 RPM and includes hardware.

Frequently Asked Questions

What is the DAYTON Double C-Face Magnetic Disc Brake used for?

The DAYTON Double C-Face Magnetic Disc Brake (2LYU7) is used for stopping and holding C-face motors in food washdown applications. It is designed for single and three phase BISSC and stainless steel C-Face motors, providing reliable braking in wet or sanitary environments.

What are the specifications of the DAYTON 2LYU7 brake?

The DAYTON 2LYU7 is a totally enclosed double C-face magnetic disc brake rated at 3 hp @ 1725 RPM. It mounts on NEMA C-Face flanges with motor frame designation 56C/140TC NEMA/IEC. It operates on 115/208-230V AC and includes mounting hardware.

Where to buy the DAYTON 2LYU7 brake worldwide?

You can source the DAYTON 2LYU7 brake through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the DAYTON Double C-Face Magnetic Disc Brake?

Install the DAYTON brake by mounting it directly onto the NEMA C-Face flange of the motor or gear reducer. Ensure the motor frame matches 56C/140TC NEMA/IEC. Follow standard torque specifications for the included hardware and verify electrical connections match the voltage rating.
